Y81-160A Metal baler
Metal scrap, steel shavings, scrap steel, scrap iron, scrap copper, scrap aluminum, aluminum shavings, disassembled automobile shell, waste oil drum
- Application
- Construction field, automotive field, electronics field, packaging field, industrial manufacturing field, household aluminum field
- Material
- Metal scrap, steel shavings, scrap steel, scrap iron, scrap copper, scrap aluminum, aluminum shavings, disassembled automobile shell, waste oil drum
Y81-160a hydraulic packer is one of the main types of compression packaging machinery. It uses compression equipment to exert pressure on various loose materials under certain compression conditions without damaging the properties of materials, so as to reduce the volume, increase the volume density, and press out packages with uniform size, large proportion and high density. It is suitable for container shipping. So as to reduce transportation costs and increase economic benefits.
1.Hydraulic drive
The hydraulic packer starts working at the station after feeding, and stops working at the time when the package is pushed out, which is a single working cycle.
2.There are two forms of bag turning and bag pushing
There are two forms of bag turning and bag pushing. There are eight extrusion forces ranging from 63 tons to 400 tons, and the efficiency ranges from 0.5 tons / hour to 20 tons / hour.
3.Rotary closed cover structure
It adopts a rotary closed cover structure, with a large opening area of the material box, especially suitable for large, empty and thin materials.
| Model | Nominal thrust(kn) | Compression chamber size(mm) | Package size(mm) | Equipped with power(kw) |
| Y81-160A | 1600 | 1600*1000*800 | (400-600)*350*350 | 22 |
